EtherTRAK-2 I/O Series, Module-10 RTD Inputs
Manufacturer: Red Lion Controls, Inc.
Mfg Product Code: E2-10RTD-D
Weight: 1.5 lb(s)
Red Lion's Sixnet series EtherTRAK-2 Ethernet enabled I/O modules provide simple and secure remote monitoring for deployments in harsh environments. EtherTRAK-2 offers a low cost per I/O point and rugged environmental ratings for reliable sensor or field data collection and communication.
Features
Analog Input Channels
- RTD input range: -200-850 deg C
- RTD overall accuracy: .05% or .5 deg C
- A/D resolution 16 bits (0.003%)
- Temperature coefficient +/- 50 ppm per °C (span and offset)
- RTD Type: 100 Ohm Platinum
- RTD Alpha: .00385 or .00392
- RTD Connections: 2 or 3-wire
- Scan time: 550 ms for all 10 channels
- Max lead wire resistance: 100 Ohms per side balanced
- RTD excitation current: 250uA pulsed to reduce self-heating
Serial Ports
RS-485 port, Screw terminals (485+, 485-, GND) (2-wire half-duplex, isolated) Isolations voltage, 150V RS-485 networking, Up to 32 (full-load) stations RS-485 distance, Up to 0.5 miles (baud rate dependent) Baud Rates from 150 to 57,600 baud Protocols: master and slave: Sixnet® and Modbus RTU / ASCII Diagnostic LEDs: Transmit (TD) and Receive (RD)
Environmental
- Operating temperature: -40 to 75°C
- MTBF: 1,294,803 Hours GB @ 40°C per MIL-HNDBK-217F2
Configuration
- Configured using Sixnet I/O Tool Kit
- Graphical User Interface (GUI)
EtherTRAK-2 I/O Series, Module-10 RTD Inputs
Brand:Red Lion
Manufacturer Product Family:EtherTRAK-2 I/O Series Modules
Analog Input:10 RTD
Feature: PoE Capable:No
Specifications
| Brand | Red Lion |
| Manufacturer Product Family | EtherTRAK-2 I/O Series Modules |
| Analog Input | 10 RTD |
| Feature: PoE Capable | No |
