• Measurement Maximum 0
• Min Operating Temperature
  • -20 °C
• Max Operating Temperature 55 °C
• Lens Material
  • Polycarbonate
• Power Supply
  • 10-30 VDC
• Delay at Power-Up
  • 120 ms
• Measurement Minimum 0
• Ingress Protection
  • IP67
• Repeatability (µs) 125
• Sensing Beam Visible Red LED
• Sensing Beam Wavelength 645
• Housing Style Rectangular
• Max Sensing Distance 3000 mm
• Sensing Mode (Detailed) Receiver
• Sensing Mode (General) Opposed
• Max Relative Humidity
  • 95% @ 50 °C
• Housing Material_
  • Polyamide
• Feature: Hazardous Area
  • No
• DeviceNet
  • No
• Feature: IO Link
  • No
• Feature: Quick Disconnect
  • No
• Feature: Audible
  • No
• Feature: Chemical Resistant
  • No
• Opposed Mode Emitter/Receiver
  • Receiver
• Feature: Water Detection
  • No
• Number of Pins
  • 4
• Output Response Time
  • 1.3 ms ON/0.7 ms OFF
• Operation
  • Light Operate
• Adjustments
  • N/A
• Feature: Timing (Hold/Delay)
  • No
• Feature: Encapsulated
  • No
• Input/Output
  • Discrete
• Feature: Remote Teach
  • No
• Feature: Intrinsically Safe
  • No
• Connection Type
  • Cable
• Country of Origin
  • US
• Cord/Cable Length
  • 2 m
• Indicator Type
  • LED
