• Measurement Maximum 0
• Min Operating Temperature
  • -20 °C
• Max Operating Temperature 50 °C
• Lens Material
  • PMMA
• Power Supply
  • 10-30 VDC
• Delay at Power-Up
  • 300 ms
• Measurement Minimum 0
• Ingress Protection
  • IP67
• Sensing Beam Visible Red Laser
• Sensing Beam Wavelength 655
• Housing Style Rectangular
• Max Sensing Distance 3000 mm
• Sensing Mode (Detailed) Laser Emitter
• Sensing Mode (General) Opposed
• Housing Material_
  • PUR
• Laser Classification
  • Class 1
• Feature: Hazardous Area
  • No
• DeviceNet
  • No
• Feature: IO Link
  • No
• Feature: Quick Disconnect
  • Yes
• Feature: Audible
  • No
• Quick Disconnect Type
  • M8
• Feature: Chemical Resistant
  • No
• Opposed Mode Emitter/Receiver
  • Emitter
• Feature: Water Detection
  • No
• Number of Pins
  • 4
• Output Response Time
  • 0.5 ms
• Adjustments
  • N/A
• Feature: Timing (Hold/Delay)
  • No
• Small Visible Spot
  • Laser
• Feature: Encapsulated
  • No
• Feature: Remote Teach
  • No
• Feature: Intrinsically Safe
  • No
• Connection Type
  • Pigtail QD
• Country of Origin
  • DE
• Indicator Type
  • LED
