• Measurement Maximum 0
• Min Operating Temperature
  • -40 °C
• Max Operating Temperature 70 °C
• Lens Material
  • Acrylic
• Power Supply
  • 10-30 VDC
• Delay at Power-Up
  • 500 ms
• Measurement Minimum 0
• Ingress Protection
  • IP67/68/69
• Repeatability (µs) 170
• Sensing Beam Visible Red LED
• Sensing Beam Wavelength 624
• Housing Style Barrel
• Max Sensing Distance 25000 mm
• Sensing Mode (Detailed) Emitter
• Sensing Mode (General) Opposed
• Max Relative Humidity
  • 95% @ 50 °C
• Housing Material_
  • Thermoplastic
• Feature: Washdown Rated
  • Yes
• Feature: Hazardous Area
  • No
• DeviceNet
  • No
• Feature: IO Link
  • No
• Feature: Quick Disconnect
  • Yes
• Feature: Audible
  • No
• Quick Disconnect Type
  • M12
• Feature: Chemical Resistant
  • Yes
• Feature: Chemical Resistant
  • Yes
• Feature: Ecolab Certified
  • Yes
• Opposed Mode Emitter/Receiver
  • Emitter
• Feature: Water Detection
  • No
• Number of Pins
  • 2
• Adjustments
  • N/A
• Feature: Timing (Hold/Delay)
  • No
• Feature: Encapsulated
  • Yes
• Barrel Diameter
  • 18 mm
• Feature: Remote Teach
  • No
• Feature: Intrinsically Safe
  • No
• Connection Type
  • Integral QD
• Country of Origin
  • US
• NEMA / UL
  • NEMA 6P
• Indicator Type
  • Indicator LED
