400 Series Heavy-Duty Mechanical Low Pressure Switch, 15 to 230 psig, 1/4" NPT-Male, SPDT, DIN EN 175301-803 Form A
Manufacturer: Noshok Inc
Mfg Product Code: 400L-3-2-15/230-8
Weight: 0.66 lb(s)
1 SPDT, 1/4 NPT Male, 15 to 230 psig Adj, DIN EN 175301-803 Form A Elec Conn Mech Press Switch
- Switch adjustment ranges from vacuum through 4,600 psig depending on model
- Standard Zinc-plated Steel with NBR diaphragm (< 225 psig); Steel piston with NBR seal (> 225 psig) wetted parts
- SPDT snap-action switch
- RoHS compliant
Applications:
- Hydraulics & pneumatics
- Mobile hydraulics
- Power generation
- Pumps & compressors
- Tank monitoring
- Water management
WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
400 Series Heavy-Duty Mechanical Low Pressure Switch, 15 to 230 psig, 1/4" NPT-Male, SPDT, DIN EN 175301-803 Form A
1 SPDT, 1/4 NPT Male, 15 to 230 psig Adj, DIN EN 175301-803 Form A Elec Conn Mech Press Switch
Measurement Maximum:230
Process Connection Type:NPT-Male
Max Operating Pressure:230 psid
Max Operating Temperature:176 °F
Case Material:Zinc Die-Cast
Measurement Minimum:15
Ingress Protection:IP65
Switch Function:SPDT
Electrical Connector Type:DIN EN 175301-803 Form A
Specifications
| Measurement Maximum | 230 |
| Process Connection Type | NPT-Male |
| Max Operating Pressure | 230 psid |
| Max Operating Temperature | 176 °F |
| Case Material | Zinc Die-Cast |
| Measurement Minimum | 15 |
| Ingress Protection | IP65 |
| Switch Function | SPDT |
| Electrical Connector Type | DIN EN 175301-803 Form A |
