400 Series Heavy-Duty Mechanical High Pressure Switch, 300 to 3,600 psig, 7/16"-20 SAE Male, Non-Adjustable, SPDT, DIN EN 175301-803 Form A
Manufacturer: Noshok Inc
Mfg Product Code: 400H-3-45-300/3600-8
Weight: 0.66 lb(s)
1 SPDT, 7/16-20 SAE J514 FIG 34B, 300 to 3,600 psig Adj, DIN EN 175301-803 Form A Elec Conn Mech Press Switch
- Switch adjustment ranges from vacuum through 4,600 psig depending on model
- Standard Zinc-plated Steel with NBR diaphragm (< 225 psig); Steel piston with NBR seal (> 225 psig) wetted parts
- SPDT snap-action switch
- RoHS compliant
Applications:
- Hydraulics & pneumatics
- Mobile hydraulics
- Power generation
- Pumps & compressors
- Tank monitoring
- Water management
WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
400 Series Heavy-Duty Mechanical High Pressure Switch, 300 to 3,600 psig, 7/16"-20 SAE Male, Non-Adjustable, SPDT, DIN EN 175301-803 Form A
1 SPDT, 7/16-20 SAE J514 FIG 34B, 300 to 3,600 psig Adj, DIN EN 175301-803 Form A Elec Conn Mech Press Switch
Measurement Maximum:3600
Max Operating Pressure:3600 psid
Max Operating Temperature:176 °F
Case Material:Zinc Die-Cast
Measurement Minimum:300
Ingress Protection:IP65
Switch Function:SPDT
Electrical Connector Type:DIN EN 175301-803 Form A
Specifications
| Measurement Maximum | 3600 |
| Max Operating Pressure | 3600 psid |
| Max Operating Temperature | 176 °F |
| Case Material | Zinc Die-Cast |
| Measurement Minimum | 300 |
| Ingress Protection | IP65 |
| Switch Function | SPDT |
| Electrical Connector Type | DIN EN 175301-803 Form A |
